Electronic Temperature Transmitter for High Pressure Applications

Description: Electronic Temperature Transmitter for High Pressure Applications Advantage: high accuracy for sanitary applications
Catalog Number: Cat. GTT-150Mpa
Price:
USD
$800.00   Login for Discount
    Please select the information you wantX
Shipping Cost:
to
Estimated Delivery Time:
Please select the country you want to ship from
+
-
Units
  • Description
  • FAQs and Tips
Description:

Genizer electronic temperature transmitter is designed for recording the temperature with output signal PT100. GTT-150Mpa is a precision temperature transmitter suited for measuring temperatures up to 150°C (300°F) and ideal for high pressure applications.

Application:

≤ 20,000 psi high pressure homogenizer or other high pressure devices.

Performance:

Sanitary for pharmaceutical applications
Long-term stability
High accuracy

Specifications
Catalog No. GTT-150Mpa
Description Genizer Electronic Temperature Transmitter
Temperature Range 0-150°C (300°F)
Standard Warranty 1 year against any manufacturing defects
Output Signal PT100
Pressure Resistance 0-20,000psi (150Mpa)
Connection Red: Power +
Black: Signal +
Accuracy 0.5%
Standard Warranty 1 year against any manufacturing defects
Application ≤ 20,000 psi homogenizer or other hydraulics
Connection 1/4" HP coupling (9/16" UNF-18-Male); 3/8" HP coupling (3/4" UNF-16-Male)

Standard Features
Materials Sanitary 316 stainless steel
Compatibility Homogenizers in all brands
Other Features Long-term stability; high accuracy
Material Standard Compliant with FDA and GMP sanitary standards
Warranty 1 year against any manufacturing defects

1.  The warranty for Genizer temperature transmitter is 1 year for laboratory homogenizer, and from 1 to 3 months for pilot and production units.
